Place of Origin:
Henan, China (Mainland)
Brand Name:
EVERSIM
Certification:
SGS,ISO
Model Number:
TCH Series
Calcined Micron Alumina Powder for Ceramics Refractorirs Industry
Alumina, chemical symbol Al2O3, molecular weight 102, pure alumina is a white amorphous powder, commonly known as bauxite, the density of 3.9-4.0g/cm3, the melting point of 2050 DEG C, the boiling point of 2980 DEG C, insoluble in water, is an amphoteric oxide, soluble inorganic acid and alkaline solution, there are four kinds of an isomer of delta beta alumina V - A - alumina alumina alumina, mainly alpha and gamma type two variants, the industry can be extracted from bauxite.
| Mesh | 325 # | 500# | W-5 | W-2 | W-1 | |
| Grade | Ceramic level | Refractory level | Ceramic level | Ceramic level | Ceramic level | Ceramic level |
| Α-Al2O3 | 98 | 90 | 95 | 95 | 95 | 90 |
| Al2O3 | 99 | 98-99 | 99 | 99 | 99 | 98-99 |
| Fe2O3 | 0.04 | 0.05 | 0.04 | 0.04 | 0.04 | 0.04 |
| SiO2 | 0.07-0.15 | 0.20Max. | 0.15Max. | 0.15Max. | 0.15Max. | 0.20Max. |
| Na2O | 0.1 | 0.25Max | 0.1 | 0.1 | 0.1 | 0.3 |
| True density | 3.95-3.97 | 3.93-3.97 | 3.95-3.97 | 3.95-3.97 | 3.95-3.97 | 3.95 |
| Calcined alumina powde Feature |
| 1) High temperature calcined, excellent chemical activity, High alumina, low sodium 2) Resonable particle size (D50=200mesh/325mesh/3-5um/1um etc),widely used in ceramic/refractories industry. 3) Product process: Bayer process technology from bauxite ore of Australia 4) Stable quality control ; SGS, ISO audited manufacturer 5) Factory located in import-export tax free area, price is best |
| Calcined alumina powder Application |
|
Widely used in Ceramics industries ---- wear resistant ceramic, electronic ceramics, small ceramic parts. ZALY's alumina suitable for dry pressing, CIP,injection moulding etc. |
| Used in Refractory industries - - Shaped refractory (firebrick etc) & Unshaped refractory (castable etc) |
| Used in glaze industry-- ceramic pigment and glazes. |
| Calcined alumina powder price's Specification |
| Application | Model | Al2O3 | Na2O | Fe2O3 | SiO2 | TiO2 | LOI | True Density | a-Al2O3 | D50 | Particle Size | Specific Surface |
| Unit | ≥ % | ≤% | ≤% | ≤% | ≤% | ≤% | g/m3 | ≥ % | um | um | m2/g | |
| Dry pressing/CIP series for ceramic | TCH-101 | 99.7 | 0.1 | 0.02 | 0.02 | 0.01 | 0.15 | 3.96 | 96 | 75 | 2--3 | 0.6-0.8 |
| TCH-102 | 99.6 | 0.1 | 0.02 | 0.02 | 0.01 | 0.15 | 3.95 | 95 | 75 | 2--3 | 0.6-0.8 | |
| TCH-103 | 99.5 | 0.2 | 0.02 | 0.02 | 0.01 | 0.2 | 3.95 | 95 | 75 | 2--3 | 0.8-1.0 | |
| TCH-105 | 99.4 | 0.3 | 0.02 | 0.02 | 0.01 | 0.2 | 3.93 | 93 | 75 | 2--3 | 0.8-1.0 | |
| Injection moulding for ceramic | TCH-213 | 99.5 | 0.2 | 0.02 | 0.02 | 0.01 | 0.15 | 3.95 | 95 | 75 | 3--4 | 0.5-0.6 |
| TCH-211 | 99.7 | 0.1 | 0.02 | 0.02 | 0.01 | 0.1 | 3.96 | 96 | 75 | 3--5 | 0.5-0.6 | |
| Refractory series | TCH-31 | 99.4 | 0.3 | 0.02 | 0.02 | 0.01 | 0.15 | 3.92 | 90 | 75 | 2--3 | 0.1-0.8 |
| TCH-30 | 99.5 | 0.3 | 0.02 | 0.02 | 0.01 | 0.1 | 3.95 | 95 | 3 | 2--4 | 1.0-1.2 | |
| TCH-33 | 99.4 | 0.3 | 0.02 | 0.02 | 0.01 | 0.15 | 3.95 | 95 | 43 | 2--3 | 0.9-1.0 | |
| TCH-003 | 99.4 | 0.3 | 0.02 | 0.02 | 0.01 | 0.13 | 3.95 | 95 | 4 | 3--5 | 1.0-1.2 | |
| TCH-35 | 99 | 0.3 | 0.02 | 0.02 | 0.01 | 0.2 | 3.9 | 90 | 43 | 3--5 | 0.9-1.0 | |
| Active A-Al2o3 | TCH-5H | 98.8 | 0.2 | 0.02 | 0.15 | 3.95 | 95 | 1 | ||||
| TCH-5L | 98.6 | 0.2 | 0.02 | 0.15 | 3.93 | 93 | 0.8 | |||||
| Glazing series | TCH-7 | 99.6 | 0.2 | 0.02 | 0.02 | 3.95 | 95 | 55 | ||||
| TCH-703 | 99.6 | 0.2 | 0.02 | 0.02 | 3.95 | 95 | 15 | |||||
| TCH-713 | 99.6 | 0.2 | 0.02 | 0.02 | 3.95 | 95 | 4 |
